ISO Automatic Hot Dip Galvanizing Plant With CNC Control System

1 set
ISO Automatic Hot Dip Galvanizing Plant With CNC Control System
Features Gallery Product Description Request A Quote
After-sales Service Provided: Engineers Available To Service Machinery Overseas
Condition: New
Type: Coating Production Line,Hot Dip Galvanizing
Substrate: Steel,Iron,Copper
Coating: Galvanizing,Painting
Product Name: Hot Dip Galvanizing Plant/Zinc Plating Equipment
High Light:

ISO automatic hot dip galvanizing plant


automatic hot dip galvanizing plant


Copper hdg hot dip galvanized

Basic Infomation
Place of Origin: China
Brand Name: Xinlingyu
Certification: IS09001:2015 , ISO 45001:2018
Payment & Shipping Terms
Packaging Details: standard export packing
Delivery Time: 90days
Payment Terms: L/C, D/A, D/P, T/T
Product Description

ISO Certificate Hot Dip Galvanizing Equipment With CNC Control System



automatic powder coating line CE standard

1. Compective price
2. Energy saving
3. good quality
4. Clean and economical
5. leading manufacturer



This system allow manual control interface in the pickling effect unqualified when artificial intervention, and real-time data recording, the formation of large data, the future through big data analysis, according to the acid concentration and temperature, the shape parameters, automatic formation of reasonable pickling process.



1. track is shared with an enclosed single beam, with a distance of about 32 meters.

2. configuration holder 2 sets, single set of hand load 10T, running speed of 10-20m/min;

3. supporting hand is equipped with vehicle control PLC, frequency converter, wireless communication module, code reader, track locator, RFID recognition system and so on to control the original device, and the protection level of electric control box is IP65.

4. system uses the sliding contact line, the collector supply of the car power supply; all units and the main control system adopts industrial control between wireless Ethernet, implementation of vehicle PLC and ground PLC master data exchange.



This system adopts the vertical arm hand type lifting device, compared with the traditional vehicle or electric hoist, with accurate positioning, no shake, can achieve a stable sling hold up and down, to avoid the slings and workpiece fall into the acid pool, and my company independent research and development of the hoisting device, with the PLC automatic control program, can be intelligent the lifting task is adjusted by the process of pickling time recording processing groove, adjust the hand task, reduce the load time, the precise control of the pickling time and automatically enter and put forward into the next process of pickling tank tank.


ISO Automatic Hot Dip Galvanizing Plant With CNC Control System 0
