Reasonable Structure Hot Rolled Acid Pickling Line Strip Width 500-1530mm

    • Reasonable Structure Hot Rolled Acid Pickling Line Strip Width 500-1530mm
    • Reasonable Structure Hot Rolled Acid Pickling Line Strip Width 500-1530mm
    • Reasonable Structure Hot Rolled Acid Pickling Line Strip Width 500-1530mm
    • Reasonable Structure Hot Rolled Acid Pickling Line Strip Width 500-1530mm
  • Reasonable Structure Hot Rolled Acid Pickling Line Strip Width 500-1530mm

    Product Details:

    Place of Origin: Jiangsu, China (Mainland)
    Brand Name: XLY

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: negotiation
    Packaging Details: standard export packing
    Delivery Time: 90 days
    Payment Terms: L/C, D/A, D/P, T/T
    Supply Ability: 10 sets
    Contact Now
    Detailed Product Description
    Brand Name:: XLY After-sales Service Provided:: Engineers Available To Service Machinery Overseas
    Name:: Acid Pickling Line Feature:: Reasonable Structure
    Color:: Customizable Usage:: Acid Pickling



    customizable high precision steel sheet acid pickling line with reasonable structure





    Specifications

    high precision steel sheet acid pickling line


    1,f actory directly
    2, better after-sale services
    3, ISO,CE
    4, on-time delivery





    high precision steel sheet acid pickling line



    Our acid pickling line could be make as per your design, to make good quality and make your profit larger is our target. so choose ou acid pickling line is the biggest treasure of ourselves. ISO 9001:2008 and CE, GB, certificates keeps our acid pickling line good quality control, your OEM,ODM of any kind of acid pickling line is acceptable for our technicians, so email me right now while you scaning us.



    we also have a good after services for you, our acid pickling line is design well so that you can control easily, we will keep 1 year repair freely. or your workers could be repair after our instructions.



    Your OEM, ODM is welcomed to us.





    Technical Parameter



    Material Strip thickness Strip width Process speed Pickling medium
    hot rolled 1.0-4.5mm 500-1530mm 40-150mm HCL








    This system adopts the vertical arm hand type lifting device, compared with the traditional vehicle or electric hoist, with accurate positioning, no shake, can achieve a stable sling hold up and down, to avoid the slings and workpiece fall into the acid pool, and my company independent research and development of the hoisting device, with the PLC automatic control program, can be intelligent the lifting task is adjusted by the process of pickling time recording processing groove, adjust the hand task, reduce the load time, the precise control of the pickling time and automatically enter and put forward into the next process of pickling tank tank.









    Process flow of continuous pickling line





    Loading manually →Coil loading car→No.1 payoff reel → No.1 payoff scraper→No.2 payoff reel →No.2 payoff scraper →No.1 five-roll straightening leveler →No.2 five-roll straightening leveler →Deflector roll→Double-layer shear →Converge pinch roll →Welding machine →No.1 bridle roll →No.1 horizontal loop →No.1 CPC →No.2 bridle roll →descaler →No.3 bridle roll →No.2 double roll CPC →Pickling →Water washing →Drying →Loop →No.4 bridle roll →Pinch CPC unit →Scrap coiling →Three-roll tension roller →Exit shear →Oiling machine →Exit deflcting pressing roll→ Tension reel →Coil unloading car →Coi receiving table





    This system allow manual control interface in the pickling effect unqualified when artificial intervention, and real-time data recording, the formation of large data, the future through big data analysis, according to the acid concentration and temperature, the shape parameters, automatic formation of reasonable pickling process.



    1. track is shared with an enclosed single beam, with a distance of about 32 meters.

    2. configuration holder 2 sets, single set of hand load 10T, running speed of 10-20m/min;

    3. supporting hand is equipped with vehicle control PLC, frequency converter, wireless communication module, code reader, track locator, RFID recognition system and so on to control the original device, and the protection level of electric control box is IP65.

    4. system uses the sliding contact line, the collector supply of the car power supply; all units and the main control system adopts industrial control between wireless Ethernet, implementation of vehicle PLC and ground PLC master data exchange.
